Radial Engineering StageBug SB-6 Stereo Isolator
Price RM1,020.00
Brand Radial Engineering
Size (L x W x H) 16 cm x 11 cm x 8 cm
Availability In Stock
Quantity
Description
Highlight
  • Isolator for balanced and unbalanced signals
  • Eliminates hum and buzz caused by ground loops
  • Exceptionally linear from 20Hz to 20kHz
  • Automatically configures for hi-Z or lo-Z signal chains

Passive Stereo Line Isolator

The StageBug SB-6 is a  two-channel passive audio isolator designed to accommodate both balanced and unbalanced signals and effectively eliminate noise when used with instruments, consumer electronics, or professional line-level devices.

Problem solver for stereo systems

The SB-6 helps remove noise from two channel audio systems, stereo guitar racks, and pedalboards. Two on-board isolation transformers provide a flat frequency response from 20Hz to 20kHz, while removing hum and buzz from ground loops. Dual ground lift switches help further reduce noise, and a -15dB pad allows you to handle high volume outputs without distortion. When using the SB-6 before a set of powered speakers or guitar amplifiers, a polarity reverse switch corrects frequency cancellation and ensures both speakers play back in phase with one another. The SB-6 is completely passive with no need for power, so it's easy to insert into any system to remove noise quickly.



Specifications
Audio circuit type: Passive Transformers
Transformer: Eclipse Custom
Frequency response: 20Hz-20KHz +/-1db
Dynamic range: >140db
Gain: -2dB
Total harmonic distortion: <0.0008% @ 1kHz
Phase Deviation: >5° @ 30Hz
Input Impedance: Varies with Load/47K
Output Impedance: 600Ω
Maximum Input: >+25dBu
Features
Input pad, 180° polarity reverse, Ground lift
Input Connectors: 1/4" TRS
Output Connectors: 1/4" TRS
General
Construction: 14 gauge steel chassis & outer shell
Size (L x W x D): 3.92" x 2.54" x 1.7" (100mm x 65mm x 43mm)
Weight: 0.9 lbs (408 grams)
Shipping size (L x W x D): 8" x 5" x 3" (203mm x 127mm x 76mm)
Shipping weight: 1.0 lbs (453 grams)
Power: Passive, no power required
Conditions: For use in dry locations only between 5°C and 40°C
